Integral Flat Aluminum Extrusion Dies

Precision Flat Dies for Solid Aluminum Profiles with Stable Extrusion Performance

Home /
Integral Flat Extrusion Dies

Profiles Produced by Integral Flat Dies

Precision Integral Flat Dies Profiles with Stable Extrusion Performance

Single-Hole Bars

Reliable Flat Dies for Solid Aluminum Profile Extrusion

Integral flat extrusion dies are one-piece aluminum extrusion dies designed for solid profile production. Featuring a simple structure, high dimensional accuracy, and cost-effective manufacturing, they are widely used for bars, strips, tubes, and industrial aluminum profiles.

Applications of Hollow Aluminum Extrusion Dies

Advantages of Integral Flat Extrusion Dies

One-piece die construction

Suitable for solid aluminum profiles

Stable metal flow distribution

High dimensional consistency

Easy maintenance and polishing

Cost-effective tooling solution

Short production lead time

Why Partner With Our Die Manufacturing Team

Integral Flat Extrusion Dies FAQ

Explore answers to the most common questions about our precision aluminum extrusion dies. Get the technical information you need to support your industrial extrusion proje

What profiles are suitable for integral flat extrusion dies?

Integral flat dies are typically used for simple solid profiles such as flat bars, strips, rods, and basic structural components that do not require internal cavities.

What is the difference between integral flat dies and porthole dies?

Integral flat dies are designed for solid profiles with direct flow extrusion, while porthole dies are used for hollow or complex profiles requiring internal bridges and welding zones during extrusion.

What aluminum alloys can be used with flat extrusion dies?

Rayven flat extrusion dies are compatible with common industrial aluminum alloys such as 6061, 6063, 6082, and other customer-specified grades depending on application requirements.

How long does custom aluminum extrusion die production take?

At Rayven, standard lead time for custom aluminum extrusion dies ranges from 4–8 weeks depending on profile complexity, size, and technical requirements.

Can Rayven manufacture dies based on customer drawings?

Yes. Rayven provides full custom die manufacturing based on customer drawings, samples, or technical specifications, including design optimization and engineering support.

How does Rayven ensure extrusion profile accuracy?

Rayven ensures high precision through CAD/CAM design, flow simulation analysis, strict machining tolerances, and trial extrusion testing before delivery.
