Flexible modular dies for high-precision aluminum profile extrusion.
We design and manufacture Modular Extrusion Dies for Efficient and Flexible Production for a wide range of profile geometries and industrial applications. Our engineering team provides customized die solutions based on your profile drawings, alloy requirements, dimensional tolerances, and production targets.
Upload your profile drawing or provide your extrusion requirements. Our engineers will design a guide groove die for optimal metal flow and top-quality profiles.
| Feature | Benefit |
| Modular components | Easy replacement & reduced downtime |
| Multi-profile compatibility | One die set for different profiles |
| High precision | Consistent extrusion quality |
| Customizable sections | Supports complex & hollow profiles |
| Durable material | Long die life & wear resistance |
Explore answers to the most common questions about our precision aluminum extrusion dies. Get the technical information you need to support your industrial extrusion proje
Semi-hollow dies include partial cavities with internal bridges, while hollow dies feature fully open cavities requiring more complex flow control.
Yes. Our engineers can design bridge-supported or multi-section semi-hollow dies according to your profile and performance requirements.
We support standard alloys such as 6060, 6061, 6063, 6005, 6082, and 7075, with custom alloy options available.
Through optimized bearing design, flow simulation, precision machining, and trial extrusion verification.
Depending on complexity, 10–25 working days from design approval to delivery.
Send us your requirements and our engineering team will provide a fast quotation and technical solution.
Rayven Company, founded in 2023, is the trading and service team of the Weilong mould manufacturing facility, which was established in Meishan in 2013.
With over 10 years of experience, we manage the entire production process in-house, from raw materials to finished products.
Our products serve a wide range of industries, including construction, manufacturing, and transportation.
